X-Keys XK-24 USB Keypad

$286.00

Product Features
  • Programme Keystrokes and Macros
  • Relegendable Keys
  • Addressable Red and Blue Backlighting
  • Fully Customisable
  • Includes Tall and Wide Keycaps

Out of stock

Join the waitlist to be emailed when this product becomes available
Categories: , ,

Description

Overview

Enhance your productivity with the X-Keys XK-24 USB Keypad. This keypad features 24 re-legendable keys with addressable blue and red backlighting for each key, making it easy to programme keystrokes and macros for your favourite applications. Key blockers along with the included tall keycaps and wide keycaps provide more opportunities for customisation. The XK-24’s co-injected case makes it suitable for desktop, mounted, or handheld work, and it can be configured for landscape or portrait orientation. Detachable feet let you set the XK-24 down at a slight angle for improved key legibility.

Key Features

  • Programme Keystrokes and Macros
  • Relegendable Keys
  • Addressable Red and Blue Backlighting
  • Fully Customisable
  • Includes Tall and Wide Keycaps
  • Includes Key Puller
  • Includes Detachable Feet
  • Free Programming Software
  • Mac and Windows Compatible
Software

Programming tools MacroWorks 3.1 for Windows and ControllerMate for Mac OS X are included, and the P.I. Engineering and Android SDKs are available for download from the manufacturer

Specifications

Operating System Use: Any OS via USB HID
Programming: Windows XP through 10, Mac OS X 10.4 through 10.10
Programming Software Windows: MacroWorks 3.1
Mac: ControllerMate for X-keys
Software Development Kits Windows (C++, C#, VB.NETT)
Linux (C++)
Android (Java)
Raw HID (any language/OS)
Emulation Modes HID keyboard, HID mouse, HID game controller
Switch Type Full travel rubber dome and carbon on gold contacts
Switch Life >1,000,000 operations
Number of Keys 24 single keys, 1 programming slide switch
Actuation Force Approx. 2.5 oz (72 g) break-over, approx. 1.5 oz (42 g) hold
Keycaps 0.625″ (16 mm) sq.; relegendable with Cherry MX compatible stem
Key Spacing 0.75″ (1.9 cm) O.C.
Backlighting 24 blue and red LEDs, individually addressable
Connector USB 2.0 type A (male)
USB Compatible with USB 1.1 through 3.0
Power Source 5 VDC
Power Consumption No Backlight: 18 mA
Blue Backlight, Full: 38 mA
Red Backlight, Full: 57 mA
All Backlights: 75 mA
Temperature Range -4 to 140° F (-20 to 60° C)
Memory Capacity Approximately 1,000 keystrokes or commands in onboard memory
Memory Type EEPROM, non-volatile memory
Environmental Rating IP 40, typical indoor office environment
Certifications FCC class B, COE, RoHS, WEEE compliant
Cord Length 56″ (1.42 m)
Dimensions (H x W x D) 5.8 x 3.8 x 0.9″ (147 x 97 x 24 mm)
Weight 10.1 oz (285.0 g)calc
